Open Front / Extreme-Duty Series
$13,086.00
| Duty Rating | Extreme-Duty |
|---|---|
| Cutting Width | 72" or 78" |
| Hydraulic Flow Range | 23-40 GPM |
| Max Cutting Diameter | up to 8" |
| Motor Style | Direct-drive radial piston motor |
* The manufacturer’s suggested retail price (MSRP) does not include shipping and taxes. Dealers set actual prices, including invoicing currency.
Description
A true workhorse built tough for industrial and commercial applications. These bad boys clear brush quickly and efficiently to improve your ROI and increase your profit. You can rely on these cutters to consistently tackle heavy brush and trees up to 8” in diameter. The unique open front “v-notch” design allows for increased operator precision cutting of trees and saplings. Tip speed and torque are optimum for efficient cutting with a massive 1” blade carrier and three high-tempered steel drop blades. But don’t just take our word for it, watch a dealer’s review.
THREE DROP-BLADE CARRIER
Number of Blades
(3) 0.5 x 4 in; non-updraft
Blade Type
High-tempered non-updraft steel blades to cut and discharge material quickly.
Blade Carrier
1” GRD-50 disc.
All Brush Wolf blade carriers are CNC balanced for ultra-smooth operation.
Long-Lasting Blades
The Brush Wolf industrial-strength drop-down blades are heat treated, have a milled edge, and are Supertuf coated to stand the test of time.
Direct-Drive Piston Motor
Experience the power of the direct-drive SAI® radial piston motor. With higher torque, you’ll get more cutting power, quicker recovery time, and less bogging down when accelerating through thick brush.
Massive Bearing Housing
We pair our direct-drive radial piston motor with a robust Eskridge® bearing housing that has a 2.625” shaft diameter and patented shaft retention system.
Motor Protection
Pressure Relief Valves: Added pressure relief valves safeguard your motor from pressure spikes and allow for a faster shutdown.
Gearbox Seal Protection
A welded seal guard collar prevents wire, twine, and vegetation from wrapping around and damaging the gearbox.
Ultra-Rugged Deck Frame
Here’s why our brush cutters last for life. We build each deck frame from a single piece of formed 1/4" thick heavy-duty steel, never pieced together. This means our frames are consistently better made and more durable, with the elimination of construction errors and frame failure. One-piece frames will always provide superior strength.
Clean Deck Design
Our one-piece deck frame construction creates a “clean deck” design that allows material to glide off, preventing unwanted debris buildup. (Think less mess and easier to clean.)
Seam Welding
Unlike our competitors, Brush Wolf’s deck and frame construction is fully boxed and continuously welded across each seam for an indestructible, rust-proof support structure.
Reinforced Gussets
We went above and beyond to make sure our cutters are crazy strong by adding boxed-in gusset reinforcements, extra bracing, and supports.
Powder-Coated Tough
Protected with the most durable finishing process, we powder coat every part to minimize rust, resist scratches, and prevent fading, so you get more life out of your brush cutter.
Push Bar
Let’s help “feed” the cutter with a welded push bar to knock down taller vegetation and trees and enhance the cutting capabilities.
Slotted Front Shield
Slotted front shield provides increased visibility while protecting the operator from debris.
Blade Access Cover
Easy access to the blade bolts for quick blade replacement.
Plug + Play Ready
Everything is ready to go upon delivery with the included quick-connect couplers, 114" hydraulic hoses encased in protective wrap, and dust caps to prevent line contamination.
Advanced Hose Routing System
We took the time to devise a well-thought-out hose routing system based on real-life situations. Using guides and STAUFF clamps, our hydraulic lines can be routed to either side. So, you choose which side works best for your machine.
Hood
The vented hood fully encloses the motor and drive components to shield them from damaging impacts and debris.
Safety Steps
Enhancing safety is our thing, so we added two non-slip, serrated metal steps for easy in and out.
Universal Quick Attach System
Time is money, so we made sure our cutters attach quickly to your machine by using the industry-standard Quick Attach system. It will only take seconds to attach/detach your machine with our universal pick-up plate.
Choose Your Color
Black, yellow, or make it your own custom color.
Parts Always Available
Brush Wolf only uses well-known industry-leading parts and components that are—and will always be—available to order 24/7 at www.brushwolf.com/parts or by calling 877-390-9857.
| PSI cont./int. | 4000 |
|---|---|
| Deck Thickness | 1/4 in |
| Motor/Gearbox Coupler | Machined steel |
| Motor Protection | Pressure relief valves |
| Blade Carrier | 1” GRD-50 disc |
| Blade Rotation | Counterclockwise |
| Blades | (3) 0.5 x 4 in; non-updraft |
| Hood | 12-ga vented hood |
